Nexus AI Server
1 / 5
| Chassis Overview | |
|---|---|
| Chassis format | All-in-one: dual controllers, internal drive bays, networking and with expansion options |
| Rack size | 2U or 5U |
| Controllers | 2 hot-swappable per chassis (dual-active). Single/dual controller support for 2U models; Dual controller support only for 5U model |
| Processor | Xeon Processor |
| Internal storage | ME5012: 12 x 3.5” drive bays; ME5024: 24 x 2.5” drive bays; ME5084: 84x 3.5” drive bays |
| System Memory | 8GB for controller and 16GB for cache (24GB total per controller) |
| Expansion Capacity | |
| Expansion enclosures | ME412 (12 x 3.5”), ME424 (24 x 2.5”), ME484 (84 x 3.5”) - All 12Gb SAS |
| Min/Max drive count | ME5012: 2/264; ME5024: 2/276; ME5084: 28/336 |
| Max raw capacity | ME5012: Up to 288TB; ME5024: Up to 184TB; ME5084: Up to 2.01PB |
| Storage media | SAS and NL-SAS drives (7.2K, 10K, SSD MU/RI, FIPS supported) |
| Network & I/O | |
| Host interface | FC, iSCSI (optical or BaseT), SAS |
| Max 32Gb FC ports | 8 per array (auto-negotiate to 16Gb) |
| Max iSCSI ports | 8 SFP+ / SFP28 (25Gb) or 8 BaseT (10Gb) per array |
| Data Optimization & Functional | |
| RAID support | RAID 1, 5, 6, 10, or ADAPT RAID |
| ADAPT RAID | Distributed erasure coding for reduced rebuild times |
| Snapshots | 1024 maximum re-direct-on-write snapshots per array |
